Features
1.A standard host can drive four 7-point, two 16-point and one 32-point nozzles simultaneously. Additional nozzles need to be customized.
2.Storage information: 1G storage capacity for print information (memory can be extended by communicating with the print-out line host PC)
3.Coding font: The printing of English letters, numeric codes, Chinese, etc. can be accommodated.
4.Coding font size: from 5 to128mm, with font width is adjustable.
5.Character width: the distance between different characters can be set at the operator interface, making it easier for the technical department to set the standard.
6.Inkjet drying time: 3-5 meters (depending on line speed in production line)
7.Character format: bold, reverse, inverted and inverted embossed characters
8.Information properties: global settings, dot size, character width, dot spacing, and print margins
9.Coding information: Chinese and English characters, numbers, date and times, counters, shifts, and graphics, etc.
10.Trigger methods: non-trigger, external photoelectric switch, encoder, etc.
11.Editing methods: sensitive trigger operation, supports for multi-point input, sensitive editing/movement of text messages according to the use.
12.Distance between the two coded messages: Distance between two coded messages: Adjustable according to production requirements, also depending on the trigger method.
13.Communication interface: the host computer can be connected to the host PC via RS232(the host PC is purchased by the customer), and can automatically print codes according to the specifications selected by the host PC.
14.Operation traceability: the system work log can be queried for easy traceability.
